Peb cov khoom ua haujlwm ntawm lub khob Laser Txawj Ua kom muaj kev kub ceev, ultra-nplua (<10μm) laser processing on glass/PET substrates. Ideal for ablation, scribing, and structuring of conductive layers (ITO, Ag, CNT, graphene, etc.) with 99% yield and ±3μm accuracy. Consumable-free, eco-friendly, and fully automated.
Saib peb laser Scribing tshuab hauv kev txiav txim: ultra-nplua kev ua yeeb yam iav
Cov ntsiab lus tseem ceeb
◎ High efficiency:
Cov iav no laser elbibing tshuab ib qho qhuav, siv cov txheej txheem dawb nrog 4000 mm / s, thiab precise {{5} {5}
◎ Precision & Yooj Yim
Cov ntawv sau lub tshuab no muaj ultra-nplua<10 μm line width processing with support for nanosecond, picosecond, and femtosecond lasers, ±3 μm file stitching accuracy, and a customizable work area of up to 1200×600 mm.
Access Muaj nqis ntau lawm
Cov tshuab laser lizing no tau muab cov dej num muaj 99%, cov neeg ua haujlwm tsis tshua muaj zog, thiab xoom kev ua kom zoo nkauj rau kev tsim khoom.
Siv tau cov ntaub ntawv
Lub tshuab ua tau ultra - kab zoo - dav Laser itching rau txheej, cov duab thaij, cov duab roj hmab, manide, xov tooj cua, thiab lwm yam, rau ntawm iav lossis zaj duab xis substrates {4 4}} nws tseem tuaj yeem ua raws li kev ncaj qha rau cov kab mob kom tsawg dua 10 microns.
Kev Ua Tshwj Xeeb
|
Laser Tau |
Fiber laser |
Ntsuab Laser |
UV laser |
|
Lub paj |
1064 nm |
532 nm |
355 nm |
|
Hwjchim |
20 W |
10 W |
10 W |
|
Mem Tes Dav |
Nanosecond, femtosecond, picosecond |
Nanosecond, picosecond |
Nanosecond, picosecond |
|
Yam tsawg kawg nkaus tsom xam qhov chaw |
Tsawg dua los yog sib luag rau 10 μm (nyob ntawm cov khoom thiab laser hom) |
||
|
Yam tsawg kawg li etch kab dav |
Tsawg dua los yog sib luag rau 10 μm (nyob ntawm cov khoom thiab laser hom) |
||
|
Kev Ceev |
Tsawg dua los yog sib npaug rau 4000 mm / s |
||
|
Ua Ntau Yam |
600 × 1200 hli / 600 × 600 hli (tus qauv loj; customerizable raws cov neeg siv khoom) |
||
|
Qhov ntau tshaj plaws ib ntu |
110 hli × 110 hli (qauv kev teeb tsa; xaiv raws li kev thov) |
||
|
CCD pib ua kom zoo |
±3 μm |
||
|
Lub cev muaj zog rooj teeb tsa Kev Raug |
±2 μm |
||
|
Tsav Lub Cev Muaj Zog Cov Lus Recovitib |
±1 μm |
||
|
Khoom Dimensions |
1650 hli L × 1300 hli W × 1670 hli H |
||
|
Cov Khoom Siv Hluav Taws Xob |
1800 kgs |
||
|
Txhawb cov ntaub ntawv tawm tswv yim |
Cov ntaub ntawv Gerber cov qauv, cov ntaub ntawv DTF, cov ntaub ntawv PLT, thiab lwm yam . |
||
Siv nyob rau hauv ntau yam kev lag luam .
ITO GAV LASER ESTCHING
Nyiaj Muab Tshuaj Txhuam Iav Laser etching
Photovoltaic iav laser scribing
Ink Iav Laser Estching
Kub Plated Iav Laser Estching
Carbon hmoov / ito conductive iav laser etching
